• Solatube Brighten Up Series






After we designed our original residential daylighting system, we realized it had great potential for commercial applications like corridors, storage rooms and small offices. The Solatube Brighten Up Series is a line of tubular daylighting devices that features Raybender Technology, a patented optical innovation built into our rooftop domes. With it, our systems effectively capture the sun’s rays at the roof level, then transfer them indoors through our highly reflective Spectralight Infinity Tubing. They can be used individually to illuminate small areas or in multiple configurations to attain predictable lighting results for larger spaces. They also can be used to create specific architectural effects like wall washes and soffit lighting. The Brighten Up Series is a brilliant solution for medium spaces with ceiling heights up to 10 ft.




Architectural and environmental integration

We believe everyone has a right to experience the benefits of natural daylight. But capturing and transmitting the sun’s rays indoors does have its difficulties. Shifting light patterns, solar heat gain, and glare are typical commercial daylighting concerns that can have a negative impact on building occupants. Fortunately, the use of progressive engineering and advanced technologies in our Solatube Daylighting Systems enables them to overcome these challenges. As a result, they provide highly predictable light output, design flexibility, and peace of mind while allowing you to meet your architectural and environmental objectives. Read below to learn more.



Optical controllability

The Brighten Up Series selectively redirects, reflects and delivers the visible spectrum of daylight to interior spaces. At the same time, it filters out infrared wavelengths to reduce daytime cooling loads, minimizing costs associated with air conditioning units. It also prevents ultraviolet light from entering the building, which can damage interiors and fade furniture and fabrics. Using selective optics, our commercial daylighting systems can even maximize capture of low-angle rays of light from the sky’s horizon and reject overpowering, high-angle rays of light from the noontime, summer sun for optimal and controlled annual daylighting performance. The result is a robust system that optimizes daylight delivery for superior comfort and light control.



Superior transmissibility

Along with delivering the highest quality daylight possible, Solatube Daylighting Systems produce minimal color / spectral shift of light. Known as high Color Temperature Maintenance (CTM), this characteristic ensures consistent color temperature throughput and stable color rendition across the visible light spectrum over the course of the year. Our systems also boast unrivaled Light Transfer Efficiency (LTE). This means they deliver maximum light throughput for greater output and enhanced multi-story daylight delivery. In short, Solatube Daylighting Systems are the pinnacle of light output, color consistency and quality of light delivery.

Extraordinary adaptability

A building’s use can change over its lifetime. That’s why Solatube Daylighting Systems are designed for adaptability. When a building is reconfigured or modified, our tubular daylighting devices can change along with it. Fixtures can be swapped out and new Effect Lenses or lighting controls can be added or removed to customize a space. Or, if a remodel demands it, the tubing can be easily rerouted to a new location. With such extraordinary adaptability, Solatube Daylighting Systems can be adjusted to conform to your building needs now as well as those in the future.

Performance predictability

When using sunlight for
commercial lighting design
applications, you want your
daylighting solution to
perform as planned.
Solatube tubular daylighting
devices feature patented optical
technologies that deliver extremely consistent daylighting, hour by hour and season by season. A Solatube Design Specialist can even provide you with IES Photometry and tools to assist you in your design process. Whatever your building type or need, we have the tools that let you customize lighting to achieve your aesthetic goals.

Affordable sustainability

Solatube products are engineered to reduce environmental impact while providing energy-efficient lighting that nurtures building occupants. By utilizing sustainable natural daylight,
our systems eliminate the need for electric lights
during the day as well as the utility needed to
generate that power. This minimizes a
building’s carbon footprint by reducing
environmental CO2 emissions.

From a financial perspective, Solatube
Daylighting Systems make good sense
because they are cost-effective and reduce
maintenance costs. In fact, they often have
lower installation costs than other fenestration
products. The end result is high-performance,
eco-friendly commercial lighting at a price that fits
your budget.


Effortless attainability

Getting a Solatube Daylighting System is effortless because we have distributors all around the globe. You can find a Solatube dealer in your area using the “dealer locator” tool at the top of this page.

Engineered reliability

We engineer our tubular daylighting devices for reliability with leakproof flashings, self-cleaning domes and UV / IR screening. The result is a commercial daylighting solution that withstands inclement weather, requires little to no maintenance, and delivers bright, beautiful daylight to occupants for years to come, giving you ultimate peace of mind.

Occupant productivity

When sunlight is allowed to enter a building, the people occupying it—whether they are working, studying, shopping or living—tend to be happier, healthier and more productive. We believe everyone deserves to experience the benefits that bright, beautiful natural lighting has to offer. The sustainable lighting design of our commercial daylighting products enhances occupants’ functionality so they can work and live at the highest levels.





Commercial Brighten Up Tab Box

Product Selection Guide

Visit Technical Resources for specifications, CAD drawings, approvals and other useful information.

Since buildings come in different sizes, so do our daylighting systems. The Brighten Up Series has four models for different lighting needs:

160 DS

The Solatube 160 DS is ideal for small spaces like offices, corridors and restrooms. It can be utilized with hard, suspended or open ceilings. Use multiples for larger rooms.

160 DSe

The Solatube 160 DSe provides the ultimate in energy-efficient daylighting. It is designed to minimize heat loss in extremely cold climates and heat gain in extremely warm climates. As a result, this product has earned an Energy Star rating.


• Tube size ≈ 10 in. (250 mm)
• Potential tube length ≈ 20 ft. (6 m)

Applications

• Small offices
• Corridors
• Storage Rooms
• Restrooms

Since buildings come in different sizes, so do our daylighting systems. The Brighten Up Series has four models for different lighting needs:

290 DS

The Solatube 290 DS provides more light than a 160 DS and, in addition to lighting small offices and corridors, can be a great solution for large areas such as classrooms and hotel lobbies when interstitial space is tight.

290 DSe

The Solatube 290 DSe has earned an Energy Star rating for its ability to minimize heat loss in extremely cold climates and heat gain in extremely warm ones. It offers the highest level of energy efficiency.


• Tube size ≈ 14 in. (350 mm)
• Potential tube length ≈ 30 ft. (9 m)

Applications

• Small offices
• Corridors
• Storage Rooms
• Rest Rooms

Flashings

Regardless of the particular roof type or deck material you use, Solatube products have a flashing designed to meet your needs. The seamless, one-piece steel construction eliminates the possibility of leaks by ensuring there are no weak points that may separate and allow water to enter.

No Pitch Flashing

• Use on low pitched or flat roofs. Available in 4 in. (100 mm) or 6 in. (150 mm) heights

• Use 6 in. (150 mm) for areas prone to heavy snow loads

• 160 DS / 160 DSe
• 290 DS / 290 DSe

Flashings

Regardless of the particular roof type or deck material you use, Solatube products have a flashing designed to meet your needs. The seamless, one-piece steel construction eliminates the possibility of leaks by ensuring there are no weak points that may separate and allow water to enter.

Pitched Flashing

• Provides a horizontal opening on a sloped roof

• 160 DS / 160 DSe
• 290 DS / 290 DSe

Flashings

Regardless of the particular roof type or deck material you use, Solatube products have a flashing designed to meet your needs. The seamed, one-piece steel construction eliminates the possibility of leaks by ensuring there are no weak points that may separate and allow water to enter.

Universal Tile Flashing

• Pitched or no pitch models are available

• 160 DS / 160 DSe
• 290 DS / 290 DSe

Flashings

Regardless of the particular roof type or deck material you use, Solatube products have a flashing designed to meet your needs. The seamless, one-piece steel construction eliminates the possibility of leaks by ensuring there are no weak points that may separate and allow water to enter.

Curb Mount Flashing

• Designed for use on all roof curbs for all roof types

• For use with any pre-built wood or manufactured metal curb

• 290 DS / 290 DSe

Ventilation Add-on Kit

The Brighten Up Series can easily transform a dark interior into a bright and beautiful space. But what about the issue of trapped humidity in restrooms, gym locker rooms or hotel laundry rooms? Solatube can handle that too. A Ventilation Add-On Kit combines daylighting and ventilation into one attractive fixture, leaving these spaces humidity-free. The streamlined design also leaves the ceiling looking orderly and uncluttered. For even more functionality, consider adding a Light Add-On Kit for a dynamic 3-in-1 unit. It’s the ideal solution for creating spaces with bright light but low humidity. Ducting and roof vent cap sold separately.

• 160 DS / DSe

The optional Light Add-On Kit easily attaches to the inside of the system’s tubing to provide incandescent or compact fluorescent lighting for nighttime use. The Solatube Daylighting System can even be placed where an existing fixture is to avoid unnecessary ceiling clutter. Commonly used in corridors and restrooms, the Light Add-On Kit is a smart solution for any space that gets used after dark.

Compact Fluorescent Light Add-On Kit

This kit works with compact flourescent bulbs only and complies with California Title 24 requirements. For the 160 DS, the light fixture houses one 26-watt compact flourescent bulb. For the 290 DS, up to two fixtures may be installed.

Universal Light Add-On Kit

This kit works with either compact fluorescent or incandescent bulbs. For the 160 DS, the light fixture holds one 23-watt maximum compact fluorescent bulb or a 100-watt maximum medium base incandescent bulb. The 290 DS light fixture holds two bulbs.

• 160 DS / 160 DSe
• 290 DS / 290 DSe

Daylight Dimmer

At times, it may be necessary to reduce the amount of bright daylight in a building—during a presentation, for instance. The optional Daylight Dimmer uses a patented butterfly baffle and a convenient wall-mounted switch to allow for simple and easy adjustments to room daylight illumination levels.

Double-Pole Double-Throw (DPDT) Switch

Daylight Dimmer Switch Kit (sold separately) includes DPDT switch, wall plate and 30 ft./9 m of cable. Multiple Daylight Dimmers can be controlled by one switch.

• 160 DS / DSe
•  290 DS / DSe

Spectralight® Infinity Extension Tube

Extension tubes can be added in increments of 16 in. (400 mm) or 24 in. (600 mm) for long runs without sacrificing performance. The secret is the unrivaled reflectivity of Spectralight® Infinity tubing, making it possible to create 90 degree angles and long tube runs up to 30 ft. (9 m).

• 160 DS / DSe
•  290 DS / DSe

Spectralight®; Infinity 0-90 Degree Extension Tube

Provides superior performance that flexible tubes can’t match. An innovative design with three built-in 30 degree angle adapters gives you the flexibility to install around obstacles. Available in 23 in. (580 mm) length.

• 160 DS / DSe
•  290 DS / DSe

Flashing Insulator

This insulating material helps to reduce condensation in cold climates when the flashing is exposed to a humid interior space. The insulator is affixed to the flashing base and the top tube slips through the opening, which provides a seal between the interior and metal flashing.

• 160 DS / DSe
•  290 DS / DSe

Flashing Turret Extensions

Use to raise the height of the Solatube dome on a roof to avoid snow, water, or shading from roof obstructions. Order additional Spectralight® Infinity Tubing to accommodate turret height. Available in 2 in. (50 mm), 4 in. (100 mm), 12 in. (300 mm), 24 in. (600 mm), 36 in. (900 mm) and 48 in. (1200 mm) sizes.

• 160 DS / DSe
•  290 DS / DSe

Dome Edge Protection Band

Made of galvanized steel, this optional component is designed for use on Class A, B or C roofs to maintain fire rating.

• 160 DS / DSe
•  290 DS / DSe

Shock Inner Dome

High Velocity Wind Zone areas such as South Florida require the Solatube Shock Inner Dome. This high impact-resistant inner dome can also be added to any installation for extra protection from extreme forces.

• 160 DS / DSe
•  290 DS / DSe

Roof Vent Cap

The Roof Vent Cap is designed for use with the Ventilation Add-On Kit (sold separately). It comes with a gravity damper to prevent back flow and is a necessity if no current vent exists.

• 160 DS / DSe


* Ventilation Add-On Kit sold separately

Curb Cap Insulation Kit

This R6 rigid, 1 in. thermal insulation is sealed and taped in the curb cap flashing base, which provides a thermal seal between the metal flashing and building envelope.

• 290 DS / DSe
